A special partnership collaboration to deliver

RF, Microwave and Wireless Training Courses

CommTech teamed up with Eastronics and Rohde & Schwarz to collaborate in delivering RF, Microwave and Wireless training courses to the Hi-Tech and the Defense Industries in Israel.

Read about the up coming RF and Microwave Engineering course here (Hebrew) or Download the “ RF and Microwave” course catalog ” (Hebrew)

R-S logo.fw-300.fw
Leading technical experts from industry and academia with many years of experience.
Demonstrations using modern RF and microwave test and measurement instruments to help reinforce the concepts introduced.
Presenting solid fundamental background as well as state of the art topics needed to accelerate your career
Instruction is focused on teaching practical, relevant and up-to-date technical skills and knowledge that can be immediately applied in the workplace

From strong leading companies

Low cost ensuring Return On Investment

Course Overview

The course duration is 65 academic hours and will be delivered over 13 meetings of 5 academic hours each
This is a comprehensive and intensive course. (see the course syllabus)
The course, is presented by  leading technical experts from industry and academia with many years of experience. (see Lecturers)
The course provides a thorough introduction to fundamental as well as state of the art topics in modern RF, Microwave and Wireless Communications engineering.
The course first constitutes solid background of basic RF concepts, including Noise, Non Linearity, Sensitivity, Dynamic Range, Transmission lines, S parameters, Impedance matching and more.
The course then reviews basic RF building blocks (Mixers, Oscillators, Filters etc.) describing how these are combined to form complete RF systems.Description of Transmitter and Receiver architectures (Superheterodyne and Direct Conversion – In-Phase and Quadrature (I-Q) Mod./Demod., Software Defined Radio and Design Considerations for RFIC transceivers)
Advanced Digital Modulations and Multiple Access methods is then presented.
The Course includes thorough description of Spectrum Analyzers, Vector Network Analyzer, Electromagnetic Waves,  Propagation of EM waves and Antennas, from the simple Dipole up to Antenna Arrays.
The course concludes by defining important test and measurement terms and methods used to characterize RF components, RF modules up to full System performance.This includes a series of practical demonstrations using modern RF test and measurement equipment.

New Course Coming Soon:

RF and Microwave Measurements

Read more


Lab tests:

  • Power measurements by several detectors (incl. peak, ave. and RMS)
  • Sensitivity measurements (for QAM and Pulse signals) with averaging (using varying BV and screens averaging)
  • Phase noise measurement of a frequency source
  • Measurement of NF (of an amplifier and SSBNF of a mixer)
  • Peak-to-Average measurement (PAPR)
  • Measurement of third-order intercept point (IP3) and SFDR
Spectrum Analyzer

Lab tests:

  • Basic calibration
  • Improved calibration (suitable for reject band of filters)
  • Measurement of BPF (S-parameters, Phase and delay response)
  • Measurement of an Amplifier (AM/AM, AM/PM, 1dB comp., Harmonics)
  • Measurement of load mismatch, and perform Single-Stub matching
Vector Network Analyzer-VNA

Lab tests:

  • Perform a broadband calibration (de-embedding)
  • EVM tests
  • Measurement of I-Q imbalance and IR (image-rejection)
  • BER measurement
  • Measurement PAPR of a detailed-QAM-constellation
  • Measurement of BW and ACPR
  • Measurement of emission mask-compliance for a WCDMA signal without and with an amplifier
Vector Signal Analyzer-VSA

Microwave and RF design using Simulation software. Session conducted in a fully equipped computer class and includes practical hands on practicing

Computers Class

A series of thorough and broad hands-on tests accomplished with advanced state-of-the-art laboratory equipment

Lab Class

Spacious classroom, Well equipped, Pleasant atmosphere. Coffee and refreshments , Easy access location, Free parking

Frontal Class


CommTech’s lecturers are not only communications professionals but also accomplished instructors, they bring unparalleled expertise and industry experience, combined with exceptional academic excellence.

This is the greatest factor distinguishing CommTech from other training companies.

Learning Management System (LMS)

Delivery of e-Learning content (including mobile), Assignments, Quizzes and Grades.
Administration, Documentation, Progress and Performance tracking, Assessment and extensive Reporting

Explore CommTech’s LMS wide range of features and available resources


Desktop, mobile, and tablet access

cst class-500

Simulation Software


The Course Syllabus now includes a whole new chapter about Microwave and RF design using Simulation software
For that porpoise we use The  CST STUDIO SUITE a 3D EM simulation software-with temporary license
This session is conducted in a fully equipped computer class and includes practical hands on practicing
The examples and exercises include Filter and Antenna design simulation
This session is led by Zeev Iluz

New Course Cycle. Opening Date:

June 22, 2016

Comprehensive and intensive syllabus, advanced learning materials and experienced lecturers means

More Knowledge, in Less Time, at Lower Cost

4600 NIS

Enroll Now!


Worldwide Course Delivery

Benefit from the Course Regardless of Your Location

Same experienced  lecturers and same Syllabus or tailored Syllabus to your exact needs and budget
The Course can be delivered “On-Site” or via the Web in Virtual Classroom in English to other locations worldwide
Please contact us for more details
